Description

FEATURES AND BENEFITS

• Spray nozzles are angled 45 degrees to the belt for a high pressure, low volume spray
• Suspends fines, making belt cleaning easier and extending blade life
• Easy-to-install system built for durability and minimal maintenance

SPECIFICATIONS

Standard-duty is for use on P-Type^®, R-Type^®, U-Type^® 18″ – 60″ (450 to 1500 mm), and EZS2 cleaners; Heavy-duty is for use on H-Type^®, U-Type^® 72″ – 96″ (1800 – 2400), and MSS, MHS, and MDWS cleaners.

• Stainless steel pole with powder coated steel clamping brackets
• Spray nozzles are spaced on 12″ (300 mm) centers
• Delivers .98 gallons (3.7 liters) per minute at 60 psi (414 kPa)
• Generally will affect moisture content of material by less than .5%
• Maximum inlet pressure is 300 psi (2069 kPa).
• Typical pressure setting is 40 – 60 psi (276 – 414 kPa).
