Description

FEATURES AND BENEFITS

• Discharges debris to one side of belt
• Blade is installed in a fixed position, eliminating any bouncing problems
• Easy adjustment with the threaded bolt for constant blade-to-belt contact
• Can be installed in minutes and requires little maintenance
• Compatible with mechanical fasteners

SPECIFICATIONS

• Maximum Belt Speed: 700 FPM (3.5 M/sec)
• Temperature Rating: -40°F to 160° F (-40° C to 71° C)
• Blade Material: UHMWPE 67-D durometer
• Belt Direction: One Way
• Grease and Chemical Resistance: Excellent
• Sticky Material Performance: Excellent
• Belt Widths: 18″ to 84″ (450 to 2100 mm)

INSTALLATION

• Versatile mounting plates that fit virtually any conveyor structure
