Description

SPECIFICATIONS

• Maximum Belt Speed: 1500 fpm (7.5 m/sec)
• Temperature Rating: -30°F to 180°F (-35°C to 82°C)
• Minimum Pulley Diameter: 48″ (1200 mm)
• UltraShear™ blade sizes available:
  • Belt Width Minus 6″ (150 mm)
  • Belt Width Minus 12″ (300 mm)
• Blade Height: 19-3/8″ (490 mm)
• Usable Blade Wear Length: 11-1/2″ (290 mm)
• Blade Material: Polyurethane 93 durometer (proprietary blend for abrasion resistance and long wear)
• Pole Diameter:  7″ (175 mm)/8″ (200 mm)
• Belt Widths: 24″ to 96″ (600 to 2400 mm)

INSTALLATION

• Pole Length: Belt width plus 79″ (2000 mm)
• Horizontal clearance required: 12″ (300 mm)
• Vertical clearance required: 27.5″ (700 mm)
• To make cleaner installation easier and quicker, see Optional Mounting Kits under Belt Cleaner Accessories category.
