Description

SPECIFICATIONS

• Maximum Belt Speed: 700 fpm (3.5 m/sec)
• Temperature Rating: -30°F to 180°F (-35°C to 82°C)
• Maximum Chevron or Cleat Height: 1/2″ (13 mm)
• Bristle Length: 3-1/4″ (83 mm)
• Overall Diameter: 12″ (305 mm)
• Shaft Diameter: 1-1/2″ (38 mm)
• Motor Voltage and HP Options:
  • 208-230/460VAC 3 Phase:
    • 1 HP: Cleaners 18″ to 42″ (450 to 1050 mm)
    • 2 HP: Cleaners 48″ to 84″ (1200 to 2100 mm)
  • 575V 3 Phase:
    • 1 HP: Cleaners 18 to 36″ (450 to 900 mm)
    • 2 HP: Cleaners 42″ to 84″ (1050 to 2100 mm)
• Available for Belt Widths: 18″ to 84″ (450 to 2100 mm)

INSTALLATION

• Shaft Length: Belt width plus 42″ (1067 mm)
• Horizontal clearance required: 12″ (305 mm)
• Vertical clearance required: 12″ (305 mm)
• To make cleaner installation easier and quicker, see Optional Mounting Brackets under Belt Cleaner Accessories category.
