Description

SPECIFICATIONS

• Maximum Belt Speed: 1500 fpm (7.5 m/sec)
• Temperature Rating: -30°F to 180°F (-35°C to 82°C)
• Minimum Pulley Diameter: 20″ (500 mm)
• MegaShear™ blade sizes available:
  • Belt Width Minus 6″ (150 mm)
  • Belt Width Minus 12″ (300 mm)
  • Belt Width Minus 18″ (450 mm)
  • Belt Width Minus 24″ (600 mm)
• Blade Height: 12.25″ (306 mm)
• Usable Blade Wear Length: 8″ (200 mm)
• Blade Material: Polyurethane 90 durometer (proprietary blend for abrasion resistance and long wear)
• Pole Diameter: 2-7/8″ (73 mm)
• Belt Widths: 24″ to 96″ (600 to 2400 mm)

INSTALLATION

• Pole length: Belt width plus 54″ (1350 mm). For longer requirements, see Pole Extenders under Belt Cleaner Accessories.
• Horizontal clearance required: 8″ (200 mm)
• Vertical clearance required: 19.5″ (488 mm)
• To make cleaner installation easier and quicker, see Optional Mounting Kits under Belt Cleaner Accessories category.
