Description

SPECIFICATIONS

• Maximum Belt Speed: 1200 fpm (6 m/sec)
• Temperature Rating: -30°F to 180°F (-35°C to 82°C)
• Minimum Pulley Diameter: 20″ (500 mm)
• Blade Height: 14″ (350 mm)
• Usable Blade Wear Length: 8″ (200 mm)
• Blade Material: Polyurethane 90 durometer (proprietary blend for abrasion resistance and long wear)
• Pole Diameter: 2-7/8″ (73 mm)
• Belt Widths: 24″ to 96″ (600 to 2400 mm)

INSTALLATION

• Pole Length: Belt width plus 54″ (1350 mm). For longer requirements, see Pole Extenders under Belt Cleaner Accessories.
• Horizontal clearance required: 7″ (175 mm)
• Vertical clearance required: 19″ (475 mm)
• To make cleaner installation easier and quicker, see Optional Mounting Kits under Belt Cleaner Accessories category.
