Description

FEATURES AND BENEFITS

• Specially designed for pulleys with diameters as small as 50 mm.
• Moisture is channeled between small raised buttons that support and grip the belt and deliver superior traction.
• Available in SBR
• Can be made in rolls up to 75m long, dependent on lagging thickness

SPECIFICATIONS

• Minimum Pulley Diameter: 2″ (50 mm)
• Thickness: 3″ (7.5mm)
• Temperature Rating: 5° F to 185° F (-15° C to 85° C)
• Rubber Compound: SBR (Styrene-Butadiene-Rubber)
• Rubber Hardness: 68 ± 3 Shore A
• FRAS (Fire Resistant Anti Static) – MHSA Certification # MSHA NO. IC-190
• Roll Width: 8″ (200 mm)
• Roll Length: 10.8 ft. (3.3 M)

INSTALLATION

• Reference Strip Selection in the sell sheet to determine the appropriate number of strips/rolls required for your application
• Flex-Lag does not require removing the pulley from the conveyor system
• A labor-saving cold vulcanization process with Flex-Lag Adhesive makes on-site installation fast, simple, and efficient
