Description

SPECIFICATIONS

• Maximum Belt Speed: 700 fpm  (3.5 m/sec)
• Temperature Rating: Up to 400°F (204°C) with spikes to 450°F (232°C)
• Usable Blade Wear Length: 3/8″ (9 mm)
• Blade Material: Impact Resistant Tungsten Carbide (works with mechanical fasteners)
• Pole Diameter: 2-3/8″ (60 mm)
• Available for Belt Widths: 18″ to 72″ (450 to 1800 mm)

INSTALLATION

• Pole Length: Blade width + 34″ (850 mm). For longer requirements, see Pole Extenders under Belt Cleaner Accessories.
• Horizontal clearance required: 4″ (100 mm)
• Vertical clearance required: 8-1/2″ – 9-1/2″ (213 – 238 mm)
